Feature:
★Neoprene bushing for upper mounting rod.
★With deflection scale.
★Fail safe design.
★Natural frequency 2.3Hz.
★Noise and vibration isolation.
★Maintenance free .
★Wide load range available.
★Spring diameter shall be not less than 0.8 times the compressed height of the spring at the design load. Springs shall have a minimum additional travel to solid equal to 50 percent of the actual deflection.
Applications:
★Hanging ceilings、
★HVAC ducting networks、
★Other suspension applications
|
Type |
Spring rate KG/mm |
Rated Defl. mm |
Rated Capacity KG |
Color Code |
|
LH-100-D |
2.0 |
50 |
90~120 |
Yellow |
|
LH-150-D |
3.0 |
50 |
120~160 |
White |
|
LH-250-D |
5.0 |
50 |
160~260 |
Green |
|
LH-350-D |
7.0 |
50 |
320~360 |
Red |
|
LH-450-D |
9.0 |
50 |
420~470 |
Brown |
|
LH-600-D |
12.0 |
50 |
570~620 |
Gray |
|
LH-750-D |
15.2 |
50 |
700~750 |
Khaki |
|
LH-850-D |
17.0 |
50 |
750~870 |
Green |
|
LH-1000-D |
20.0 |
50 |
870~1050 |
Blue |
