Feature:
★Allows easy inspection since the spring deflection can be visually checked.
★Easy to install and suited to support lightweight equipment.
★Quick and easy installation.
★Weather resistant finish.
★Spring diameter shall be not less than 0.8 times the compressed height of the spring at the design load. Springs shall have a minimum additional travel to solid equal to 50 percent of the actual deflection.
Applications:
★Pumps and compressors、Fans and Blowers、Air handling units
|
Type |
Rated Capacity KG |
Spring Rate KG/mm |
Rated Defl. mm |
Color Code |
|
LC-020-P |
10~20 |
0.8 |
25 |
Yellow |
|
LC-030-P |
20~30 |
1.2 |
25 |
Green |
|
LC-050-P |
30~50 |
2 |
25 |
Red |
|
LC-070-P |
50~80 |
2.8 |
25 |
Blue |
|
LC-090-P |
80~100 |
3.6 |
25 |
Brown |
|
LC-120-P |
100~130 |
4.8 |
25 |
Gray |
|
LC-150-P |
130~150 |
6 |
25 |
White |
|
LC-180-P |
150~180 |
7.2 |
25 |
Orange |
|
LC-250-P |
180~260 |
10.2 |
25 |
Purple |
